Electric parameters Input voltage: 100V~240V AC，50/60Hz Power consumption: 660W @ 220V Rated current: 3.0A/220V Power factor: PF>0.9
Light sources Light sources：500W laser module Color temperature：9500K Rated life：12000hrs
Prism/frost： 2 prism wheels: 1 wheel (an 8-facet circular prism+ a 4-facet linear prism ) +1 wheel (a 9-facet circular prism + a gradient prism), prisms can be overlapped. Other prism options available.
Frost 1 pc frost filter
Focus DMX linear focus
Strobe/Dimmer Double flag strobe，0.3-25 F.P.S. / linear dimmer
Movements Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function |
Beam angle Beam/Spot mode angle：0.8°-26° Wash mode : 1.8°-30° Unique super wide angle/under wash mode : 38°-60°
Control International standard DMX 512 signal ,5-pin XLR connectors Short Mode 23 channels，standard Mode 28 channels, extended mode 31 channels Self test mode
Other functions Pan and Tilt speeds adjustable Lamp hours and fixture hours displayed Modular construction easy for maintenance Wireless receiver Wireless transmitter ( Optional) ArtNet control( Optional)
Housing and ingress protection Cast aluminum and high temperature and UV resistant ABS with IP66
Weight Net weight：37.8Kg
Ambient temperature 45 °C at maximum Note: If the ambient temperature is below 0°C, preheat the fixture for some time( less than 20 min based on actual situation normally) before striking the light source
|
|
|
|
|
|
【Version：20241125】 |
