Input voltage |
Control |
||
|
100V~240V AC，50/60Hz |
International standard DMX 512 signal ,5-pin XLR connectors |
||
|
Short Mode15 channels，standard Mode 17channels |
|||
|
Power consumption |
extended mode 18channels |
||
|
650W @ 220V |
Self test mode |
||
|
|
|||
| Light sources |
Other functions |
||
| 500W laser module(9500K,12000hrs) |
Pan and Tilt speeds adjustable |
||
|
Lamp hours and fixture hours displayed |
|||
| Prism/frost |
Modular construction easy for maintenance |
||
|
3 prism wheels: (an 8-facet circular prism+ a 4-facet linear prism) |
Wireless receiver |
||
|
+ (a 16-facet circular prism + a frost filter) |
Wireless transmitter(Optional) |
||
|
prisms overlapped. Other prism options available |
ArtNet and sACN(Optional) |
||
|
|
|||
|
Focus |
Housing and ingress protection |
||
| DMX linear focus |
Cast aluminum and high temperature and UV resistant ABS with IP66 |
||
|
|
|||
|
Strobe/Dimmer |
Weight |
||
|
Double flag strobe,0.3-25 F.P.S. / linear dimmer |
Net weight:39.2 Kg |
||
|
|
|||
|
Movements |
Operation temperature |
||
|
Pan (0°-540°),Tilt( 0°-270°) with auto positioning correction function |
-20°C-45°C |
||
|
Note: If the ambient temperature is below 0°C, preheat the fixture for some time |
|||
|
Beam angle |
(less than 20 min based on actual situation normally) before striking the light source |
||
|
Beam angle: 0.8° |
|||
|
|
|||
|
|
【Versio：20240701】 |
| Color Wheel | |||
|
1 color wheel: 19 colors + open |
|||
|
Macros and bi-directional rainbow effects with variable speeds |
|||
|
|
|||
| Fixed Gobo | |||
|
1 fixed gobo wheel：30 gobos |
|||
|
Shakable at variable speeds and bi-directional rotation at variable speeds |
|||
