Input voltage | a single fixture or multiple ones and store brightness | ||
100V-240V AC，50/60Hz | values into the fixtures | ||
Input power | CRI mode | ||
1900W @ 220V | Running at high CRI mode via DMX channel to ensure high CRI optical effect | ||
| Light sources | Control | ||
1500W white LED module (6500K) | International standard DMX512 signal and RDM function | ||
| CRI : Ra≥95、R9≥95, Lamp Life : ≥20000hrs | 31channels in short mode, 35channels in standard mode,49channel in extended mode | ||
DMX512 wireless control | |||
| Cto | Art Net protocol（optional） | ||
Linear CTO system(0-100%, 1800K-6500K) | sACN protocol(optional) | ||
Beam angle | Control Interface | ||
1/2θ（peak）:7°～40°, with 16 bit precision | DMX512 ports（5-pin） | ||
1/10θ（peak）:12°～60°, with 16 bit precision | Ethernet port RJ45 | ||
| Focus | Other functions | ||
DMX linear focus | Pan and Tilt speeds adjustable，Pan and Tilt swappable and invertible | ||
High precision magnet sensor for positioning | |||
Dimmer | 3.2-inch touch color screen, Chinese and English menus | ||
Linear electronic dimmer 0-100% with 16 bit control | Screen automatic lock –up while standby | ||
3 dimmer speeds | Error diagnostic system with sensors | ||
4 dimmer gamma curves | Smart fan cooling system | ||
Dimmer frequency(1.2K-25K) adjustable, suitable for 4K high speed video camera | Display of fixture hours and software versions | ||
Modular construction for easy maintenance | |||
Strobe | Isolated input signals | ||
Electronic strobe, 0.3~25 F.P.S, optional synchronized or non-synchronized strobe | Firmware update via DMX cable | ||
| |||
Head movement | IP rating | ||
Pan 540o, Tilt 270o with auto position correction and 16 bit control | IP20 | ||
Advanced macros | Operation temperature | ||
Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K | Ambient temperature at maximum：45°C | ||
Standard color macros: 89 color options based on standard color chart | |||
Fan mode | Weight | ||
Standard mode and theater modes.Theater mode is quiet mode | Net weight 43.5 KG | ||
| |||
Brightness calibration function | |||
With brightness calibration function to calibrate initial brightness for | |||
| CMY | |||
CMY linear coloring mixing system with macros | |||
| 2 Color Wheels | |||
Color Wheels 1：Red, Green, Blue, Orange , Pink, Light cyan,+ open | |||
Color Wheels 2：Dark Red, Amber, Tea red, Apple Green, Dark Magenta, UV+ open | |||
Full color/half color/linear color | |||
Bi-directional rainbow effect with variable speeds | |||
| Framing | |||
1 Framing module | |||
4 framing blades to make graphics with different sizes and shapes | |||
Framing module rotates bi-directionally up to 360 °and continually, each framing blade produces full curtain effect | |||
