Input voltage | Beam angle | ||
200V~240V AC，50/60Hz | linear zoom 6°- 50° with 16 bit function | ||
| Input power | Control | ||
| 640W@220V AC | DMX512 , 5 pin interfaces | ||
RDM control protocol | |||
Light Source | 14 channels in short mode, 17 channels in standard mode | ||
500W White LED(9000K),20000hrs, Ra≥70( Option: Ra≥90) | and 19 channels in extended mode | ||
Master/Slave synchronized mode | |||
Prism | Stand-alone mode | ||
1pc of 3 facet circular prism | |||
Bi-directional rotation with variable speeds and indexing function | Other function | ||
1pc of 4 facet linear prism | Total hours displayable | ||
Bi-directional rotation with variable speeds and indexing function | English and Chinese menus | ||
Built-in sensor diagnostic system | |||
| Effect wheel | Software versions displayable | ||
| 1 double effect wheel | Input signal isolation | ||
| both rotating in the same direction or opposite one with variable speeds | Modular Structure for easy maintenance | ||
Water wave Wheel | Housing | ||
1pcs, bi-directional rotation with variable speeds | High temperature ABS+ High tensile cast aluminum , IP66 | ||
Focus | Operation Temperature | ||
| DMX linear Focusing | Highest ambient temperature 45℃ | ||
Note: If the ambient temperature is below -20℃ | |||
| Dimmer | reset a projector before pre-heating it for more than 30 minutes | ||
| 0-100% Linear adjustment | |||
Strobe | Net weight | ||
Electronic strobe, 0.3~25 F.P.S | 28.5 Kg | ||
Tilt | |||
270° | |||
| 1 Color Wheels | |||
7 colors+ Open | |||
Half color effect, rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Rotating Gobo | |||
1 Rotating Gobo Wheel: 8 replaceable gobos+ Open, Glass or Metal Gobo | |||
Bi-directional Rotation with variable speeds | |||
With Indexing Function | |||
Gobo Shake Effect with Variable Speeds | |||
Bi-directional Scrolling with Variable Speeds | |||
