Input voltages | Fan mode | ||
100V~240V AC, 50/60Hz | Standard mode and theater modes. Theater mode is quiet mode | ||
Input Power | Control | ||
550W @ 220V | DMX512, 5 pin interfaces | ||
RDM protocol and DMX wireless control(optional sACN protocol) | |||
Light source | Ethernet Protocol | ||
350W, White LED module, CRI : Ra≥70 | 25channels in short mode, 30channels in standard mode, | ||
35channels in extended mode | |||
CTO | Master/Slave mode | ||
Linear CTO (0-100%) | Stand-Alone mode | ||
Master mode | |||
Prism | |||
1pc, 3-facet circular prism, bi-directional rotation at variable speeds, | Other functions | ||
indexble. Other optional prisms are available. | Adjustable Pan & Tilt speeds | ||
Pan and Tilt invertible and swappable | |||
Frost | Lamp’ s and fixture’ s hours displayed | ||
0-100% linear with 1pc frost filter | Color touch Chinese/English screen, display invertible and touch keys | ||
Intelligently controllable fans | |||
Focus | Sensor diagnostic system | ||
DMX linear focus | Input signal isolated, modular construction for easy | ||
maintenance, DMX channel voltages monitoring | |||
Zoom | Non-touchable magnetic sensor for positioning, | ||
DMX linear focus | signal feedback, absolute position memory, auto-positioning | ||
after power-off or DMX signal disrtuption | |||
Iris | Firmware upgrade via DMX cable | ||
5-100% linear with macros | Optional ethernet port | ||
Strobe | Housing | ||
Electronic strobe 0.2~25 F.P.S, optional pulse, | High temperature ABS, IP20 | ||
synchronized or non-synchronized strobe at slow, | |||
medium and fast speeds | Weight | ||
22Kg | |||
Head movement | |||
Pan 540o, Tilt 270o with auto position correction | Ambient temperature | ||
Temperature at maximum 40°C | |||
Beam angle | |||
Beam/Spot Mode: 4°- 40° Linear Adjustment | |||
Wash Mode: 5°- 45° Linear Adjustment | |||
With 16 bit control function | |||
| CMY | |||
CMY color mixing system with macros | |||
| 1 Color Wheels | |||
1 Color wheel: 12colors+ Open, | |||
rainbow effect with bi-directional and variable speeds, | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 7 gobos +Animation Effect+Open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
| Rotating Gobo | |||
1 Rotating gobo wheel:7 Rotating Gobos +Open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
