Input voltage | Strobe | ||
100V-240V AC,50/60Hz | Electronic strobe, 0.3~25 F.P.S | ||
| Input power | Head movement | ||
1450W@220V | Pan 540o, Tilt 270o with auto position correction and 16 bit control | ||
1600W@100V | |||
| Control | |||
Light sources | International standard DMX512 signal and RDM function | ||
1000W white LED module,6900K | 38channels in short mode, 42channels in standard mode,57channel in extended mode | ||
| Ra≥95, R9≥95 ( Optional highly bright version: Ra≥70) | |||
Manufacturers Rated Lamp Life:>20000hrs | Control interface | ||
| DMX512 ports（5-pin) | |||
Cto | Ethernet port RJ45 | ||
Linear CTO system(0-100%, 1800K-6500K) | |||
Other functions | |||
Effect wheel | Pan and Tilt speeds adjustable | ||
1 animation effect wheel, bi-directional rotation with varied speeds | Pan and Tilt swappable and invertible | ||
High precision magnet sensor for positioning | |||
Iris | 3.2-inch touch color screen, Chinese and English menus, | ||
Linear iris 5-100% with macros | Screen automatic lock –up while standby | ||
Error diagnostic system with sensors | |||
Prism | Smart fan cooling system | ||
1 pc of 4-facet circular prism, bi-directional rotation with varied speeds with indexing function | Display of fixture hours and software versions | ||
Modular construction for easy maintenance | |||
Frost | Isolated input signals | ||
1 heavy frost filter (0-100% linear) | Firmware update via DMX cable or USB port | ||
DMX512 wireless reciever | |||
Beam angle | DMX512 Transmitter(Optional) | ||
Linear zoom 6°～ 54° with 16 bit precision | ArtNet and sACN(Optional) | ||
Focus | IP Rating | ||
Linear focus with auto-focus function | IP20 | ||
Dimmer | Operation temperature | ||
Linear electronic dimmer 0-100% with 16 bit control | Ambient temperature 45℃ at maximum | ||
3 dimmer speeds | |||
4 dimmer gamma curves | Weight | ||
Dimmer frequency adjustable between 1.2K and 25K | Net weight 45Kg | ||
| CMY | |||
CMY linear coloring mixing system with macros | |||
| Color Wheel | |||
1 Color Wheels: 6 colors+Open | |||
| Color Wheel: Red, Green, Blue, Orange, Pink, Light cyan, Open | |||
| Bi-directional rainbow effect with variable speeds | |||
Full color/half color/linear color | |||
| Rotating Gobo | |||
1 rotating gobo wheel: 6 exchangeable+ open | |||
Bi-directional rotation, indexing, shake with varied speeds | |||
bi-directional scrolling with varied speeds | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 7 exchangeable gobos+ open | |||
Shake effect with varied speeds and bi-directional rotation with varied speeds | |||
| Framing | |||
Framing module:4 framing blades to make graphics with different sizes and shapes | |||
| Each blade to make full curtain effect .Continual and bi-directional rotation for the whole module | |||
