Input Voltage | Beam Angle | ||
120V~240VAC，50/60Hz | Beam: 5°~ 45° | ||
Spot :11°~ 46° | |||
Input Power | Wash: 8°~ 48° | ||
600W @ 220V | |||
Control | |||
Light Source | Projector and lamp information readable, external DMX value received and thermal sensor | ||
500W White LED Engine(7800K±200K) | built-in for error and malfunction analysis Preset memory | ||
Unintentional head move to cause power-off, quiet fans for cooling | |||
CRI | International standard DMX 512 protocol, 5-pin interface 22channels in short mode and | ||
CRI >72 (Standard) | 28channels in standard mode | ||
CRI>90 (Optional) | |||
Optionalwireless Controlmodule/Rdm Module | |||
Colors | Compliant with USITT DMX-512（1986 and 1990）and 512-AFull DMX for fidelity and | ||
1Color wheel: 7colors + Open | DMX framing integrity | ||
CMY+CTO | Auto-detecting DMX framing size and speed | ||
<5ms DMX delay | |||
Fixed Gobo Wheel/Effectwheel | Frequency range: 2402-2480 MHz | ||
1 fixed gobo wheel: 7 gobos+open | |||
1 fire effect wheel | Housing | ||
High temperature ABS and aluminum , IP20 | |||
Rotating Gobo Wheel | |||
1 rotating gobo wheel: 7 gobos +open Gobo diameter Ф19.5mm, 4mm thick | Operation Temperature | ||
Ambient temperature at maximum：45°C | |||
Prism/Frost | Ambient temperature at minimum：-5°C | ||
1 4-facet prism | |||
1 Frost | Net Weight | ||
21.5Kg | |||
Focus | |||
DMX linear focus | Accessories | ||
Safety cord 1 Pc | |||
Dimmer /Strobe | Clamp 2 Pc | ||
Strobe at variable speeds | Foldable clamp 2 Pc (Optional) | ||
0-100% linear dimmer | User manual 1 Pc | ||
Head Movement | |||
Pan 540o, Tilt 270o with 16 bit control | |||
