INPUT VOLTAGES | CONTROL | ||
208V~240V AC，50/60Hz | DMX512 5 pin interfaces | ||
RDM and Art-Net controls with options for RJ45 interfaces | |||
INPUT POWER | wireless DMX control and SCAN protocol | ||
1800W@220V | 35channels in short mode | ||
Maximum current: 10A@187V | 41channels in standard mode and 54channels in extended mode | ||
Power factor: PF>0.9 | Self-test mode | ||
LIGHT SOURCE (WITH 1400W BALLAST AND IGNITER) | OTHER FUNCTIONS | ||
OSRAM lok-it 1400/PS (6000K,CRI >95,single ended ,750hrs) | Adjustable Pan & Tilt speed | ||
Lamp and Total hours displayed | |||
CTO | Color touch screen ,English and Chinese menus | ||
0-100% linear CTO | Display invertible and Auto fan speed control | ||
Energy saving ballast | |||
PRISM | Built-in sensor diagnostic system | ||
1pc of 3 facet prism | Input signal isolation | ||
Bi-directional rotation with variable speeds and indexing function | Modular Structure for easy maintenance | ||
DMX channel monitoring | |||
FROST | Magnet sensor positioning with signal feedback, | ||
1pc frost filter, linear frost effect | absolute position memeroy | ||
Auto-positioning after DMX signal disruption or power off | |||
FOCUS | Firmware upgrade via DMX or USB | ||
DMX linear Focusing | |||
HOUSING | |||
DIMMER | High temperature ABS, IP20 | ||
0-100% Linear adjustment | |||
two options for dimmer curves: linear dimmer curve and square law curve | NET WEIGHT | ||
As for square law curve | 48Kg | ||
it has wider range and is more smooth in black environments | |||
PACKAGING | |||
IRIS | Standard: carton 840x640x738(mm) | ||
5-100% linear adjustment with macros | Optional: flight case 720x580x900(mm) | ||
STROBE | OPERATION TEMPERATURE | ||
Double shutter blades, 0.3~25 F.P.S | Highest ambient temperature 40°C | ||
HEAD MOVEMENT | ACCESSORIES | ||
Pan 540o, Tilt 270o with auto position correction | G clamps 2 Pcs | ||
XLR Connectors 1 SetMale and female | |||
BEAM ANGLE | Safety cord 2 Pc | ||
linear zoom 6°～ 55°with 16 bit function | User manual 1 Pc | ||
NOISE | |||
Less than 45 dBA | |||
| CMY | |||
CMY linear mixing system with macros | |||
| Color Wheel | |||
1 color wheel: 7colors+ open, Half Color effect | |||
rainbow effect with bi-directional and variable speeds, | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
1 fixed gob wheel:4 fixed gobos+ Open | |||
Gobo Shake Effect with variable speeds, bi-directional scrolling with variable speeds | |||
| Rotating Gobo | |||
1 Rotating Gobo Wheel: 6 replaceable gobos+ open, Glass or Metal Gobo | |||
| Bi-directional Rotation with variable speeds | |||
With Indexing Function,Gobo Shake Effect with Variable Speeds,Bi-directional Scrolling with Variable Speeds | |||
| Framing | |||
1 Framing Module: 4 Framing Blades | |||
Framing Module continual rotation with many graphics of different sizes and shapes | |||
4 Framing blades to make full curtain effect | |||
