Input Voltages | Other Functions | ||
100-240V AC, 50/60Hz | LED board temperature display | ||
Fixture usage time display | |||
Power Consumption | Brightness level control | ||
700W@220V | Timer control | ||
DMX mode, setting status | |||
Light Source | operation mode and user memory data can be transmitted by synchronous control | ||
PHILIPS 216x3W(RGBW, RGB/Lemon, RGB/Amber, RGW/Amber), 50,000 hrs | DMX512 wireless receiver(optional) | ||
DMX512 wireless transmitter(optional) | |||
Strobe | |||
Electronic strobe, 0.5-33 F.P.S | Physical | ||
Housing: high-intensity die-casting aluminum, IP67 | |||
Dimmer | Ambient working temperature: -20°C~40°C | ||
0-100% linearly adjustable | |||
Weight | |||
Light Angle | Net weight: 30kg | ||
Beam angle(1/2peak) θ1/2 : 9° | |||
Packaging | |||
Control | Standard: carton 815x785x420(mm) | ||
International DMX512, 3 pins interface | Optional: flight case | ||
Standard mode 6 channels and extended mode 11 channels, | |||
HIS mode 5 channels and HSIC mode 6 channels | Accessories | ||
Master-slave mode, test mode | G clamp, 2 pcs | ||
16 Preset memories, 16 user memories | Signal adapter cord, 2 pc | ||
| Preset memories and user memories can be loaded by control channels | Safety cord, 1pc Optional: omega clamp, 2 pcs | ||
| Color System | |||
RGBW, RGB/Lemon, RGB/Amber, RGW/Amber , with macro | |||
