Input Voltages | Control | ||
100-240V AC, 50/60Hz | International DMX512, 5 pins interface | ||
RDM control protocol | |||
Power Consumption | Short mode 16 channels, standard mode 20 channels and | ||
570W@220V, 600W@100V | extended mode 21 channels | ||
Self-test mode | |||
Light Source | User memory and preset memory | ||
PHILIPS Platinum 300S Flex(7,800±300K), 6000 hrs | |||
Other Functions | |||
Strobe | Adjustable pan & tilt speed | ||
Mechanical strobe 0.3-20 F.P.S with macro | LCD display screen | ||
Fixture and lamp usage time display | |||
Dimmer | Modular structure for easy maintenance | ||
Mechanical dimmer 0-100% linearly adjustable | DMX512 wireless receiver | ||
DMX512 wireless transmitter(optional) | |||
Prism and Frost | |||
Three prisms (8-facet+16-facet+linear)+frost+open | Weight | ||
Net weight: 29Kg | |||
Focus | |||
Motorized linear focus | Packaging | ||
Standard: carton 490x460x668(mm) | |||
Head Movement | Optional: flight case 745x516x835(mm), 2 in 1 | ||
Pan 540°, tilt 270° with auto position correction | |||
Accessories | |||
Light Angle | G clamp, 2 pcs | ||
Beam angle: 2° | 5 Pins XLR connector, 1 set | ||
Safety cord, 2 pcs | |||
Physical | Power cord, 1 pc | ||
Housing: cast aluminum and high temperature UV resistant ABS, IP66 | Optional: Ω clamp, 2 pcs | ||
| Ambient temperature: maximum 40°C | |||
| Color Wheel | |||
1 Color wheel: 12 dichroic color filters+CTO plus open | |||
Rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 16 gobos plus open | |||
Bi-directionally rotatable, and shakable effect at variable speeds | |||
| Rotating Gobo | |||
1 Rotating gobo wheel: 12 interchangeable gobos plus open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
