Input Voltages |
Head Movement |
||
|
100-240V AC, 50/60Hz |
Pan 540°, tilt 270° with auto position correction |
||
|
|
|||
|
Power Consumption |
Control | ||
|
1100W@230V |
International DMX512, 5 pins(optional 3 pins) interface |
||
|
RDM control protocol, ART-Net protocol(optional) |
|||
|
Light Source |
Short mode 35 channels, standard mode 38 channels and extended mode 54 channels |
||
|
800W white LED, (8,000K, 20,000 hrs) |
Self-test mode |
||
|
CRI≥90(optional) |
|||
|
Other Functions |
|||
| Strobe |
Adjustable pan & tilt speed |
||
|
Double shutter blades, 0.3-25 F.P.S |
LCD display screen |
||
|
Fixture and lamp usage time display |
|||
|
Dimmer |
Modular structure for easy maintenance |
||
|
0-100% linearly dimming |
DMX512 wireless receiver |
||
|
DMX512 wireless transmitter(optional) |
|||
|
CTO |
|||
|
Independent 0-100% linear CTO |
Physical |
||
|
Housing: cast aluminum and high temperature UV resistant ABS, IP65 |
|||
|
Prism |
Ambient temperature: maximum 45°C |
||
|
One 4-facet prism, bi-directional rotation with variable speeds |
|||
|
Weight |
|||
|
Frost |
Net weight: 58Kg |
||
|
One linear frost filter |
|||
|
Packaging |
|||
|
Effect |
Standard: carton 855x655x815(mm) |
||
|
1 Interchangeable graphic effect wheel, bi-directional rotation with variable speeds |
Optional: flight case 695x535x820(mm) |
||
|
|
|||
|
Iris |
Accessories |
||
|
5-100% linearly adjusted with macros |
G clamp, 2 pcs |
||
|
5 Pins XLR connector, 1 set |
|||
|
Light Angle |
Safety cord, 1 pc |
||
|
6°~56° |
Power cord, 1 pc |
||
|
Optional: Ω clamp, 2 pcs |
|||
|
Focus/Zoom |
|||
|
DMX linear focus/zoom |
|||
| CMY | |||
| CMY linear mixing system with macros | |||
| Color Wheel | |||
|
1 Color wheel: 6 dichroic color filters plus open |
|||
|
Rainbow effect with bi-directional and variable speeds |
|||
|
Stepping/linear color changing |
|||
| Fixed Gobo | |||
|
1 Fixed gobo wheel: 7 interchangeable gobos plus open |
|||
|
Bi-directionally rotatable, and shakable effect at variable speeds |
|||
| Rotating Gobo | |||
|
1 Rotating gobo wheel: 6 interchangeable gobos plus open |
|||
|
Bi-directionally rotatable, and shakable at variable speeds |
|||
| Framing | |||
|
Bi-directionally rotatable, and shakable at variable speeds |
|||
|
Framing module endless rotation with many graphic of different sizes and shapes, curtain effect |
|||
